<h2>Tech Specs & Customization</h2>
<div class="help_support">
<div><img src="https://cdn.uvation.com/marketing/2024/02/Reen-Singh-Uvation-Experts.png" alt="expert_image" /></div>
<div>
<div class="question">Still have Questions?</div>
<a href="tel:+1 833 631 7912">Call +1 833 631 7912</a></div>
</div>
</div>
<div class="cds--row">
<div class="cds--col-lg-6">
<div>
<h4>Firewall Performance</h4>
<ul>
<li>Firewall inspection throughput: 105 Gbps</li>
<li>Threat Prevention throughput: 82 Gbps</li>
<li>Application inspection throughput: 86 Gbps</li>
<li>IPS throughput: 76.5 Gbps</li>
<li>DPI SSL throughput: 21 Gbps</li>
<li>VPN throughput: 32 Gbps</li>
<li>New connections/sec: 860,000</li>
<li>Max SPI connections: 40,000,000</li>
<li>Max DPI connections: 40,000,000</li>
<li>Max DPI SSL connections: 40,000,000</li>
</ul>
</div>
<div>
<h4>VPN Capabilities</h4>
<ul>
<li>Site-to-site tunnels: 25,000</li>
<li>IPSec VPN clients: 2,000 (up to 10,000)</li>
<li>SSL VPN licenses: 256 (up to 3,000)</li>
<li>Encryption: DES, 3DES, AES (128/192/256-bit)</li>
<li>Authentication: MD5, SHA-1, Suite B</li>
<li>Key exchange: Diffie Hellman Groups 1, 2, 5, 14v</li>
<li>Certificate support: Verisign, Thawte, etc.</li>
<li>Supported VPN clients: Windows, Mac OS, Linux, Android, iOS</li>
</ul>
</div>
<div>
<h4>Networking</h4>
<ul>
<li>IP address assignment: Static, DHCP, PPPoE, L2TP, PPTP</li>
<li>Multi-instance firewall: 12 tenants</li>
<li>NAT modes: 1:1, many:1, flexible NAT, PAT, transparent</li>
<li>Max VLAN/tunnel interfaces: 1024</li>
<li>Routing: BGP, OSPF, RIPv1/v2, policy-based</li>
<li>QoS: Bandwidth control, DSCP, 802.1e</li>
<li>Authentication: LDAP, RADIUS, SSO, CAC, etc.</li>
<li>VoIP: Full H.323 v1–5, SIP</li>
<li>Standards: TCP/IP, UDP, ICMP, IPSec, DHCP, SNMP, IEEE 802.3</li>
</ul>
</div>
</div>
<div class="cds--col-lg-6">
<div>
<h4>Hardware</h4>
<ul>
<li>USB 3.0 Ports: 3</li>
<li>Console Port: 1</li>
<li>Management Port: 1</li>
<li>Storage: 2 x 480 GB SSD</li>
<li>Interfaces: 6 x 100GbE QSFP28, 4 x 40GbE QSFP+, 16 x 10GbE SFP+</li>
<li>Form Factor: 2U Rack Mountable</li>
<li>Power Supply: Dual, Redundant, 1,200W</li>
<li>Fans: 10</li>
<li>Max Power Consumption: 1065W</li>
<li>Total Heat Dissipation: 2845.3 BTU</li>
<li>Dimensions: 68.6 x 43.8 x 8.8 cm</li>
<li>Weight: 26 kg (Shipping: 37.3 kg)</li>
</ul>
</div>
<div>
<h4>Management & OS</h4>
<ul>
<li>Operating System: SonicOSX 7.0</li>
<li>Management: CLI, SSH, Web UI, REST APIs</li>
<li>SSO Users: Up to 100,000</li>
<li>Max APs Supported: 128</li>
<li>Logging: Analyzer, Syslog, Local Log, IPFIX, NetFlow</li>
</ul>
</div>
<div>
<h4>Compliance & Reliability</h4>
<ul>
<li>High Availability: Active/Passive with Stateful Sync</li>
<li>FIPS 140-2 Compliant: Yes</li>
<li>Certifications (in progress): NDPP, ICSA AV/FW, VPNC, IPv6, UC APL</li>
<li>Regulatory Model: 2RK05-0FE</li>
<li>Major Regulatory: FCC, CE, VCCI, UL, RoHS, REACH, etc.</li>
<li>Operating Temp: 0°–40°C</li>
<li>Storage Temp: -40°–70°C</li>
<li>Humidity: 10–95% non-condensing</li>
</ul>
</div>
<div>
<h4>Manufacturing</h4>
<ul>
<li>Part Number: 02-SSC-2722</li>
</ul>
</div>
</div>
</div>
</div>High-performance SonicWall NSsp 15700 Essential Edition with 1 Year TotalSecure delivers enterprise-grade security, threat prevention, and scalable protection for complex networks.
