IP address assignment |
Static (DHCP, PPPoE, L2TP and PPTP client), Internal DHCP server, DHCP Relay |
Multi-Instance Firewall |
Max Tenants per Hardware: 12 |
NAT modes |
1:1, many:1, 1:many, flexible NAT (overlapping IP), PAT, transparent mode |
Logical VLAN and tunnel interfaces (maximum) |
1024 |
Wire Mode |
Yes |
Routing protocols |
BGP, OSPF, RIPv1/ v2, static routes, policy‑based routing |
QoS |
Bandwidth priority, max bandwidth, guaranteed bandwidth, DSCP marking, 802.1e (WMM) |
Authentication |
LDAP (multiple domains), XAUTH/RADIUS, SSO, Novell, internal user database, Terminal Services, Citrix, Common Access Card (CAC) |
VoIP |
Full H323-v1-5, SIP |
Standards |
TCP/IP, UDP, ICMP, HTTP, HTTPS, IPSec, ISAKMP/IKE, SNMP, DHCP, PPPoE, L2TP, PPTP, RADIUS, IEEE 802.3 |
FIPS 140-2 Compliant |
Yes |
Certifications (in progress) |
FIPS 140-2 (with Suite B) Level 2, UC APL, VPNC, IPv6 (Phase 2), ICSA Network Firewall, ICSA Anti-virus, Common Criteria NDPP (Firewall and IPS) |
High availability |
Active/Passive with stateful synchronization |
