IP address assignment |
Static (DHCP, PPPoE, L2TP and PPTP client), Internal DHCP server, DHCP relay |
NAT modes |
1:1, 1:many, many:1, many:many, flexible NAT (overlapping IPs), PAT, transparent mode |
VLAN interfaces |
256 |
Routing protocols |
BGP4, OSPF, RIPv1/v2, static routes, policy-based routing |
QoS |
Bandwidth priority, max bandwidth, guaranteed bandwidth, DSCP marking, 802.1e (WMM) |
Authentication |
LDAP (multiple domains), XAUTH/RADIUS, TACACS+, SSO, Radius accounting NTLM, internal user database, 2FA, Terminal Services, Citrix, Common Access Card (CAC) |
VoIP |
Full H323-v1-5, SIP |
Standards |
TCP/IP, UDP, ICMP, HTTP, HTTPS, IPSec, ISAKMP/IKE, SNMP, DHCP, PPPoE, L2TP, PPTP, RADIUS, IEEE 802.3 |
Certifications (in progress) |
FIPS 140-2 (with Suite B), UC APL, IPv6 (Phase 2), ICSA Network Firewall, ICSA Anti-virus, Common Criteria NDPP (Firewall and IPS) |
High availability |
Active/Passive with stateful synchronization |
